Agilent Technologies 81101A - Page 102

102
Specifications
Agilent 81101A Specifications
Typical Delays
Mode from to
typ.
value
External Width Ext Input Strobe/Trigger Out
OUTPUT
8.5 ns
22.5 ns
Trigger Gated Ext Input Strobe/Trigger Out
OUTPUT
12.0 ns
29.0 ns
Continuous Strobe/
Trigger Out
OUTPUT 17.0 ns
Ext. clock signal
as pulse period
CLK-IN Strobe/Trigger Out
OUTPUT
12.0 ns
29.0 ns
