Agilent Technologies 81101A Reference Guide

97
Specifications
Agilent 81101A Specifications
Level Parameters
Level parameters can be entered as high/low level in terms of voltage or
current or offset/amplitude.
Pulse Performance
Clock Sources
It is possible to select between three clock sources, the startable
oscillator (VFO), the internal PLL, or the External Clock. In Triggered
Mode the PLL can be used as the trigger source for the VFO, without the
need of an additional source.
Level Specifications (50
Ω
into 50
Ω
) (1k
Ω
into 50
Ω
)
Amplitude: 100 mVpp to 10.0 Vpp 200 mVpp to 20.0 Vpp
Level Window –10.0 V to +10.0 V –20.0 V to + 20.0 V
Level Accuracy
(in +
19 V level window):
+
(3% Amplitude + 75 mV) +(3% Amplitude + 150 mV)
Resolution: 10 mV 20 mV
Pulse Performance Agilent 81101A
Overshoot, Preshoot, Ringing: +5% of amplitude ±20 mV
Settling time: 30 ns typical
Baseline noise: 8 mV RMS typical
Dynamic Crosstalk < 0.1% typical
