89
3
3Specifications
In this chapter you will find the specifications of the Agilent 81101A
Pulse Generator.
At the end of this chapter, “Pulse Parameter Definitions” on page 105
provides detailed information on the definition of the pulse parameters
used by the instrument.
NOTE Warranted Performance
Specifications describe the instrument’s warranted performance. Non-
warranted values are described as typical. All specifications apply after a
30 minute warm-up phase with 50 Ohm source, a 50 Ohm load resistance
and separate channels. They are valid from 0
°
C to 55
°
C ambient
temperature.
