Applications The Logging Application

232 Agilent 8163A/B, 8164A/B, and 8166A/B User’s Guide, Fourth Edition

Analysing a Logging Application

You can access the Logging Analysis screen after the logging

application completes, by completing the following instructions:

20 You cannot access the Logging Analysis screen from the graph. If

you are viewing the graph, press [Close].

Figure 149 The Logging Measurement Screen - Measurement Completed
