Agilent Technologies 8481A - Page 37

General Information
Chapter 2 27
1 MHz to 2 GHz < 1.10 (0.048)
2 to 4.2 GHz < 1.30 (0.130)
8483A
100 kHz to 600 kHz < 1.80 (0.286)
600 kHz to 2 GHz < 1.18 (0.083)
8485A
50 to 100 MHz < 1.15 (0.070)
0.1 to 2 GHz < 1.10 (0.048)
2 to 12.4 GHz < 1.15 (0.070)
12.4 to 18 GHz < 1.20 (0.091)
18 to 26.5 GHz < 1.25 (0.111)
26.5 to 33 GHz < 1.40 (0.166)
8487A
50 to 100 MHz < 1.15 (0.070)
0.1 to 2 GHz < 1.10 (0.048)
2 to 12.4 GHz < 1.15 (0.070)
12.4 to 18 GHz < 1.20 (0.091)
18 to 26.5 GHz < 1.25 (0.111)
26.5 to 40 GHz < 1.30 (0.130)
40 to 50 GHz < 1.50 (0.20)
Table 2-2 Power Sensor SWR and Reflection Coefficient
Frequency Maximum
SWR
(Reflection
Coefficient)
System SWR
Uncertainty
Performance
Limit (Rho -
System Rho
Uncertainty)
Actual
Measurement
