Agilent Technologies 8481A - Page 38

General Information
Chapter 228
8481B
10 MHz to 2 GHz < 1.10 (0.048)
2 to 12.4 GHz < 1.18 (0.083)
12.4 to 18 GHz < 1.28 (0.123)
8482B
100 kHz to 2 GHz < 1.10 (0.048)
2 to 4.2 GHz < 1.18 (0.083)
8481H
10 MHz to 8 GHz < 1.20 (0.091)
8 to 12.4 GHz < 1.25 (0.112)
12.4 to 18 GHz < 1.30 (0.130)
8482H
100 kHz to 4.2 GHz < 1.20 (0.091)
8481D
10 to 30 MHz < 1.40 (0.167)
0.03 to 4 GHz < 1.15 (0.070)
4 to 10 GHz < 1.20 (0.091)
10 to 15 GHz < 1.30 (0.130)
15 to 18 GHz < 1.35 (0.112)
Table 2-2 Power Sensor SWR and Reflection Coefficient
Frequency Maximum
SWR
(Reflection
Coefficient)
System SWR
Uncertainty
Performance
Limit (Rho -
System Rho
Uncertainty)
Actual
Measurement
