24 Chapter1
Quick Start Guide
What You'll Find in This Chapter
Introducing Your New Spectrum Analyzer
Table 1-1 Spectrum Analyzer Operating Range
Spectrum
Analyzer
Amplitude Range Frequency Range
8560E/EC −145 dBm to +30 dBm 30 Hz to 2.9 GHz
8561E/EC −145 dBm to +30 dBm 30 Hz to 6.5 GHz
8562E/EC −148 dBm to +30 dBm 30 Hz to 13.2 GHz
8563E/EC −148 dBm to +30 dBm 9 kHz to 26.5 GHz
30 Hz to 26.5 GHz
(with Option 006)
8564E/EC −147 dBm to +30 dBm 9 kHz to 40 GHz
30 Hz to 40 GHz
(with Option 006)
8565E/EC −147 dBm to +30 dBm 9 kHz to 50 GHz
30 Hz to 50 GHz
(with Option 006)
