26 Chapter1
Quick Start Guide
Initial Inspection
Part Numbers of Accessories Supplied
Item Part Number
Front cover 5063-0274
Mass memory module 85620A
(not included with Option 104)
BNC cable, 23 cm (9 in.) 10502A
4 mm hex (Allen) wrench 8710-1755
Power cord see Figure 9-2 on page 672
Fuse: 5 A, 250 V (supplied in fuse holder) 2110-0709
Adapter, Type-N (m) to SMA (f) (8563E/EC only) 1250-1250
Adapter, Type-N (m) to BNC (f) 1250-0780
(not included with Option 026)
(2 per Option 002)
Adapter, SMA (m) to BNC (f) 1250-1200
(Option 026, 8564E/EC or 8565E/EC only)
Adapter, APC 3.5 (f) to APC 3.5 (f) 5061-5311
(Option 026 only)
Adapter, K (f) to 2.4 mm (f) 1250-2187
(8564E/EC or 8565E/EC only)
Adapter, 2.4 mm (f) to 2.4 mm (f) 1250-2188
(8564E/EC or 8565E/EC only)
Termination, 50 Ω SMA (m) 1810-0118
Power holes will occur when using adapters and cables beyond their specified range.
