Chapter 6 355
Programming Command Cross Reference
Programming Command Versus Front Panel Key
CALIBRA TION ADJALL REALIGN LO &IF Initiates power-on adjustment
sequence.
ADJCRT CRT ADJ PATTERN Initiates CRT adjustment
patterns.
ADJIF IF ADJ ON OFF ADJ
CURR IF STATE
FULL IF ADJ
Initiates IF adjustment sequence.
AMPCOR AMPCOR ON OFF Turns on and off the correction for
system flatness.
AMPCORDATA EDIT AMPCOR Enters amplitude correction data.
AMPCOR SIZE Indicates the number of correction
points.
AMPCOR RCL RECALL AMPCOR Recalls ampcor data.
AMPCOR SAVE SAVE AMPCOR Saves ampcor data.
FDIAG FREQ DIAG LO FREQ
SAMPLER FREQ
SAMPLER HARMONIC,
FRAC N FREQ,
POSTSCLR, RAW OSC
FREQ
Returns frequency of specified
oscillator.
RLCAL REF LVL ADJ Calibrates reference level.
CONFIGURATION EXT MXR EXT MXR PRE UNPR Selects either preselected or
unpreselected external mixing
mode.
ID DATECODE OPTIONS Returns the model number of
analyzer used.
OP Returns the display lower-left and
upper-right coordinates.
PLOT COPY Sends analyzer display to a
plotter.
PLOTORG PLOT ORG DSP GRT Selects scaling points for plot.
PLOTSRC PLOT ANNOT
PLOT GRATICUL
PLOT ORG DSP GRAT
PLOT TRACE A
PLOT TRACE B
Specifies plot source.
PRINT COPY Sends analyzer display to a
printer.
REV DATECODE &OPTIONS Returns analyzer firmware
revision date.
SER DATECODE &OPTIONS Returns analyzer serial number.
COPY PLOT COPY with COPY DEV
PRNT PLT
Sends analyzer display to a
plotter.
PRINT COPY with COPY DEV
PRNT PLT
Sends analyzer display to a
printer.
Table 6-2 Programming Command Functional Index
Function
Category
Command Corresponding Key
Function
Description
