480 Chapter7
Language Reference
FULBAND Full Band
Example
Lines 40 through 160 are only applicable with firmware revisions
≤920528 or with Option 008.
10 OUTPUT 718;"IP;MXRMODE EXT;"
20 INPUT "ENTER DESIRED FREQUENCY BAND (KAQUVEWFDGY OR
J)",Fulband$
30 OUTPUT 718;"FULBAND ";Fulband$;";"
40 OUTPUT 718;"MKN EP;"
50 PRINT "POSITION THE MARKER ON THE DESIRED SIGNAL."
60 PRINT "PRESS THE ANALYZER HOLD KEY, THEN PRESS CONTINUE
."
70 PAUSE
80 OUTPUT 718;"SNGLS;TS;SIGID AUTO;DONE?;"
90 ENTER 718;Done
100 OUTPUT 718;"IDFREQ?;"
110 ENTER 718;Idfreq
120 IF Idfreq<0 THEN
130 PRINT Idfreq
140 ELSE
150 PRINT "NO SIGNAL FOUND"
160 END IF
170 OUTPUT 718;"CONTS;"
180 LOCAL 718
190 END
D 110.0 to 170.0 30− 30 dB
G 140.0 to 220.0 36− 30 dB
Y 170.0 to 260.0 44− 30 dB
J 220.0 to 325.0 54− 30 dB
Table 7-5 Unpreselected External-Mixer Frequency Bands
Frequency
Band
Frequency
Range(GHz)
Mixing
Harmonic
Conversion
Loss
