Agilent Technologies 8564EC - Byte Static RAM (8564 EC and 8565 EC)

512 Chapter10
Controller Section
32 K-Byte Static RAM
32 K-Byte Static RAM
The static RAM stores the ADC samples that are taken when the Fast
ADC circuitry is in the "write" mode. When not in the "write" mode, the
static RAM is read by the CPU to retrieve the fast ADC data. The 8-bit
DFADC bus connects the outputs of latches within U35 to the data port
of static RAM U21.
