82 Chapter2
Adjustment/Diagnostic Software
To Use the Diagnostics
Log Offset Coarse DAC A4U102B State 1
Log Offset Fine DAC A4U102C State 1
Local Oscillator Tune DAC A4U102D State 1
*Refer to steps 1 and 3 of ”DAC Control” for spectrum analyzer state settings, unless
otherwise noted.
Table 2-3 DAC Control Recommended Instrument State
DAC Reference
Designator
Recommended Instrument
State*
