3-10
Common Commands
*RST (Reset)
Memory display Off
Waveform source First available channel or memory 1
Memory type Waveform
Math
Function Function 1
Function state Off
Operator Magnify
Operand 1 First available channel or memory 1
Operand 2 First available channel or memory 1
Horizontal scaling Track source
Vertical scaling Track source
Channel
Display On (lowest number installed channel;
others are off)
Scale
50
μW/div or 10 mV/div
Offset 0.0 V or 0 W
Units Volts (or watts)
Filter Dependent on module
Wavelength Wavelength 1
Bandwidth Dependent on module
Histogram
Mode Off
Axis Horizontal
Window source First available channel
Size Horizontal - 4.0 divisions
Vertical - 5.0 divisions
X1 position 25 ns
Y1 position 1 division up from bottom, value
depends on module
X2 position 33 ns
Y2 position 1 division down from top, value
depends on module
Utilities
Cal Output 5.0 mv
Calibration Details Off
Self Test Scope Self Tests
Service Extensions Off
Table 3-4. Default Setup (3 of 4)
