4-10
Root Level Commands
MTEE
<string> A six-character alphanumeric model number in quotation marks. Output is determined by
header and longform status as in Table 4-5.
Example 10 OUTPUT 707;":Model? FRAME"
MTEE
Command :MTEE <mask>
This command sets a mask into the Mask Event Enable register. A “1” in a bit position enables
the corresponding bit in the Mask Test Event Register to set bit 10 in the Operation Status
Register. <mask> is the decimal weight of the enabled bits. Only bits 0 and 1 of the Mask Test
Event Register are used at this time. The following table shows the enabled bits for each use-
ful mask value. Bits that are not marked as enabled for a mask are blocked from affecting the
operation status register.
Query :MTEE?
Returned Format [:MTEE] <mask><NL>
MTER?
Query :MTER?
This query returns the current value of the Mask Test Event Register as a decimal number
and also clears this register. Bit 0 (COMP) of the Mask Test Event Register is set when the
Mask Test completes. Bit 1 (FAIL) of the Mask Test Event Register is set when the Mask Test
fails. This will occur whenever any sample is recorded within any region defined in the mask.
Table 4-5. Model? Returned Format
HEADER LONGFORM RESPONSE
ON OFF ON OFF
X X 86100A
X X 86100A
X X :MOD 86100A
X X :MODEL 86100A
Table 4-6. Enabled Bits for Mask Values
Mask Value Bit 1 FAIL Bit 0 COMP
0
1•
2•
3••
