18-46

Measure Commands

VAMPlitude

10 OUTPUT 707;”:SYSTEM:HEADER OFF”

20 OUTPUT 707;”:MEASURE:TVOLT? -.250,+3”

VAMPlitude

Command :MEASure:VAMPlitude [<source>]

Calculates the difference between the top and base voltage of the specified source. Sources

are specified with the MEASure:SOURce command or with the optional parameter following

the VAMPlitude command.

<source> is the {CHANnel<N> | FUNCtion<N> | RESPonse<N> | WMEMory<N>} where <N>

is 1, 2, 3, or 4.

Mode Oscilloscope and TDR modes.

Query :MEASure:VAMPlitude? [<source>]

The query returns the calculated difference between the top and base voltage of the specified

source.

Returned Format [:MEASure:VAMPlitude] <value>[,<result_state>]<NL>

<value> is the cCalculated difference between the top and base voltage. If SENDvalid is ON,

the <result_state> is returned with the measurement result. Refer to Table 18-4 on

page 18-39 for a list of the result states.

Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”

20 OUTPUT 707;":MEASURE:VAMPLITUDE?2"

VAVerage

Command :MEASure:VAVerage {CYCLe | DISPlay} [,<source>]

Calculates the average voltage over the displayed waveform. The source is specified with the

MEASure:SOURce command or with the optional parameter following the VAVerage com-

mand. The CYCLe parameter specifies to measure the average voltage across the first period

of the display. This option is valid in oscilloscope mode only. The DISPlay parameter specifies

to measure all the data on the display. This option is valid in both oscilloscope and TDR

modes. The <source> is {CHANnel<N> | FUNCtion<N> | WMEMory<N> | RESPonse<N>}

where <N> is an integer, from 1 through 4.

Mode Oscilloscope and TDR (DISPlay option only) modes.

Query :MEASure:VAVerage? {CYCLe | DISPlay}, [<source>]

The query returns the calculated average voltage of the specified source.

Returned Format [:MEASure:VAVerage] <value> [,<result_state>]<NL>

<value> is the calculated average voltage. If SENDVALID is ON, the <result_state> is

returned with the measurement result. Refer to Table 18-4 on page 18-39 for a list of the

result states.

Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”

20 OUTPUT 707;”:MEASURE:VAVERAGE? DISPLAY”
