Measure Commands

VBASe

Command :MEASure:VBASe [<source>]

Measures the statistical base of the waveform. The source is specified with the MEA-

Sure:SOURce command or with the optional parameter following the VBASe command.

<source> is {CHANnel<N> | FUNCtion<N> | RESPonse<N> | WMEMory<N>} where <N>, for

channels, is dependent on the type of plug-in and its location in the instrument. For functions

<n> is 1 or 2. For waveform memories (WMEMORY): 1, 2, 3, or 4. For TDR responses: 1, 2, 3,

or 4.

Mode Oscilloscope and TDR modes.

Query :MEASure:VBASe? [<source>]

The query returns the measured voltage value at the base of the specified source.

Returned Format [:MEASure:VBASe] <value>[,<result_state>]<NL>

<value> is the voltage at the base of the waveform. If SENDvalid is ON, the <result_state> is

returned with the measurement result. Refer to Table 18-4 on page 18-39 for a list of the

result states.

Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”

20 OUTPUT 707;”:MEASURE:VBASE?”

VMAX

Command :MEASure:VMAX [<source>]

Measures the absolute maximum voltage present on the selected source waveform. The

source is specified with the MEASure:SOURce command or with the optional parameter fol-

lowing the VMAX command. <source> is {CHANnel<N> | FUNCtion<N> | RESPonse<N> |

WMEMory<N>} where <N>, for channels is dependent on the type of plug-in and its location

in the instrument. For functions: 1 or 2. For waveform memories (WMEMORY): 1, 2, 3, or 4.

For TDR responses: 1, 2, 3, or 4.

Mode Oscilloscope and TDR modes.

Query :MEASure:VMAX? [<source>]

The query returns the measured absolute maximum voltage present on the selected source

waveform.

Returned Format [:MEASure:VMAX] <value>[,<result_state>]<NL>

<value> is the absolute maximum voltage present on the waveform. If SENDvalid is ON, the

<result_state> is returned with the measurement result. Refer to Table 18-4 on page 18-39

for a list of the result states.

Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”

20 OUTPUT 707;”:MEASURE:VMAX?”

VMIN

Command :MEASure:VMIN [<source>]
