Agilent Technologies 8753ES Reference Guide

5-11
Hardkey/Softkey Reference
Analyzer Functions
accepts a power sensor calibration factor % for the
segment.
brings up the segment modify menu and segment edit
(calibration factor menu) which allows you to enter a
power sensor's calibration factors. The calibration factor
data entered in this menu will be stored for power sensor
A.
sets the preset state of interpolated error-correction on or
off.
brings up the segment modify menu and segment edit
(calibration factor menu) which allows you to enter a
power sensor's calibration factors. The calibration factor
data entered in this menu will be stored for power sensor
B.
indicates the currently selected cal kit and leads to the
select cal kit menu, which is used to select one of the
default calibration kits available for different connector
types. This, in turn, leads to additional menus used to
define calibration standards other than those in the
default kits (refer to “Modifying Calibration Kits” in the
“Operating Concepts” chapter of the user’s guide). When a
calibration kit has been specified, its connector type is
displayed in brackets in the softkey label. The cal kits
available are listed below, refer to the softkey descriptions
for these softkeys for more information.
—
—
—
—
—
—
—
—
—
—
—
this default selection establishes the TRL/LRM
LINE/MATCH standard as the characteristic impedance.
CAL FACTOR
CAL FACTOR SENSOR A
CAL INTERP ON off
CAL FACTOR SENSOR B
CAL KIT [ ]
2.4mm 85056
2.92* 85056K
2.92mm other kits
3.5mmC 85033C
3.5mmD 85033D/E
7-16 85038
7mm 85031
N 50
Ω
85032B/E
N 50
Ω
85032F
N 75
Ω
85036
TRL 3.5mm 85052C
CAL Z0: LINE Z0
