5-22
Hardkey/Softkey Reference
Analyzer Functions
adds electrical delay to the input B reference plane for any
B input measurements including S-parameters.
extends the reference plane for measurements of S
11
, S
21
,
and S
12
.
extends the reference plane for measurements of S
22
, S
12
,
and S
21
.
toggles the reference plane extension mode. When this
function is on, all extensions defined above are enabled;
when off, none of the extensions are enabled.
selects an (optional) external disk drive for
SAVE/RECALL.
leads to a series of service tests.
appears during sequence modification, when external disk
is selected. FILE0 is the default name. A new name can be
entered when you save the state to disk.
saves the display to the disk drive as a graphic file when
pressed. The format of the graphic file is
determined by the selection.
saves the display to the disk drive as a text file
when is pressed. The form of the text file is
determined by the selection.
supplies a name for the saved state and or data file. Brings
up the TITLE FILE MENU.
provides access to the file utilities menu.
defines the load in a calibration kit as a fixed (not sliding)
load.
is used only with a polar or Smith format. It changes the
auxiliary response value of the fixed marker. This is the
second part of a complex data pair, and applies to a
magnitude/phase marker, a real/imaginary marker, an
R+jX marker, or a G+jB marker. Fixed marker auxiliary
response values are always uncoupled in the two channels.
To read absolute active marker auxiliary values following
a operation, the auxiliary value can be reset
to zero.
leads to the fixed marker menu, where the stimulus and
response values for a fixed reference marker can be set
arbitrarily.
