Preset State and Memory Allocation
Preset State
Frequency List
Frequency List Empty
Edit Mode Start/Stop, Number of Points
Response Conditions
Parameter (ES) Channel 1: S11
Channel 2: S21
Channel 3: S12
Channel 4: S22
Parameter (ET) Channel 1: Refl
Channel 2: Trans
Channel 3: Refl
Channel 4: Trans
Conversion Off
Format Log Magnitude (all inputs)
Display Data
Color Selections
Same as before
Dual Channel Off
Active Channel Channel 1
Auxiliary Channel Disabled
Frequency Blank Disabled
Test Set Switch (ES) Continuous
Split Display 2X
Intensity 100%
Beeper: Done On
Beeper: Warning Off
D2/D1 to D2 Off
Title Channel 1 = Empty
Channel 2 = Empty
IF Bandwidth 3700 Hz
IF Averaging Factor 16; Off
Table 8-1 Preset Conditions (Continued)
Preset Conditions Preset Value
Preset
To Next Page
