Preset State and Memory Allocation
Preset State
Smoothing Aperture 1% SPAN; Off
Phase Offset 0 Degrees
Electrical Delay 0 ns
Scale/Division 10 dB/Division
Calibration
Correction Off
Calibration Type None
Calibration Kit (ES) 7-mm, type-N 75-ohm (Option 075)
Calibration Kit (ET) Type-N 50 Ohms
Enhanced Reflection Calibration Off
System Z0 50 Ohms
Velocity Factor 1
Extensions Off
Port 1 0 s
Port 2 0 s
Input A 0 s
Input B 0 s
Chop A and B (ES) On
Chop RFL & TRN (ET) On
Power Meter Calibration Off
Number of Readings 1
Power Loss Correction Off
Sensor A/B A
Interpolated Error Correction On
Electronic Calibration (ECal)
Module A (information may not be loaded)
Omit Isolation On
Isolation Averages 10
Manual Thru Off
Table 8-1 Preset Conditions (Continued)
Preset Conditions Preset Value
To Next Page
