2-14
8753ET Specifications and Characteristics
Instrument Specifications
Table 2-11 Test Port Input
8753ET Test Port Input
Description
Specification
System Bandwidths
3000 Hz 10 Hz
Trace Noise
a
a. Trace noise is defined for a ratio measurement. For the transmission
measurement (B/R), the connection is a 0 dB loss thru with 0 dBm into the
receiver. For a reflection measurement (A/R), an open is used on the
Reflection port with +5 dBm reflected power.
Magnitude
300 kHz to 3GHz < 0.006 dB rms < 0.001 dB rms
3 GHz to 6 GHz < 0.010 dB rms < 0.002 dB rms
Phase
300 kHz to 3GHz < 0.038° rms < 0.006° rms
3 GHz to 6 GHz < 0.070° rms < 0.012° rms
Table 2-12 Test Port Input
8753ET Test Port Input
Description Specification Supplemental
Information
Reference Level
Magnitude
Range ± 500 dB
Resolution 0.001 dB
Phase
Range ± 500°
Resolution 0.01°
Stability (Ratio Measurement)
Magnitude
300 kHz to 3 GHz 0.02 dB/°C, typ.
3 GHz to 6 GHz 0.04 dB/°C, typ.
Phase
300 kHz to 3 GHz 0.05 deg/°C, typ.
3 GHz to 6 GHz 0.20 deg/°C, typ.
