Agilent Flowmeter ADM1000
Operating Instructions
Agilent Flowmeter
ADM1000
Packing List
Thank you for choosing Agilent's ADM1000 Flowmeter. When
unpacking the box, please make sure it contains the following:
Principle of Operation
The ADM1000 provides continuous, real time measurements
of all NON-CORROSIVE AND NONFLAMMABLE GAS FLOWS.
Unlike bubble flowmeters, the ADM1000 operates without liq-
uids, bubbles or glass parts.
When activated, a solenoid actuated valve interrupts the gas
flow momentarily. The gas flow moves a diaphragm in propor-
tion to the flow rate. This movement is transformed by the
microprocessor into a digital value which is displayed instantly.
Adjusting the Viewing Angle
The flip down wire stand will give you a better viewing angle
when the ADM1000 is placed above bench level. Simply pull
the stand down until it is in the locked position.
Taking a Flow Measurement
Make sure that the flow to be measured is within the range
of the flowmeter. Over ranging the flowmeter can damage
the transducer. Briefly press the on/split button. The display
will flash the message WARMUP . During this time, the micro-
processor will run a self-diagnostic test to ensure the system
is functioning correctly. Always turn the flowmeter on before
connecting to a flow source.
Connect the flexible tubing to the gas source to be measured,
wait for the reading to stabilize (1 - 2 seconds) and record the
reading.
1 ADM1000 Flowmeter
(battery included)
1 Instruction Manual
