Agilent Technologies E4402B Configuration Guide

11
ESA-E Upgrade Options
Add additional options or upgrade your existing ESA-E spectrum analyzer
Available models:
E4401BU (9 kHz to 1.5 GHz)
E4402BU (30 Hz to 3.0 GHz)
E4404BU (30 Hz to 6.7 GHz)
E4405BU (30 Hz to 13.2 GHz)
E4407BU (30 Hz to 26.5 GHz)
Ordering instructions
To upgrade an existing ESA-E Series
spectrum analyzer, order the corresponding
model number followed by a ‘U’ and the
desired option number. (E440xBU-xxx)
For more information see:
http://www.agilent.com/find/esa-e_upgrades/
Hardware capabilities and performance
Replace GPIB connection (A4H) with serial port 1AX Not compatible with Option A4H; occupies one expansion slot X X
GPIB connection A4H Not compatible with Option 1AX; occupies one expansion slot X X
Wide offset phase noise improvement and
ACPR dynamic range extension
120 Occupies one expansion slot X X
Time-gated spectrum analysis 1D6 X X
50 Ω tracking generator (9 kHz to 3.0 GHz) 1DN Operates to 1.5 GHz on E4401B X X
Narrow resolution BW 1DR X X
TV trigger and picture on screen B7B Requires BAA; not compatible with Option 060 X X
Cable fault location accessory kit (50 Ω) B7K Requires Option 1DN and Option 225 or BAH X
FM demodulation/deviation BAA Not compatible with Options 304, or 106; occupies one expansion slot X X
Fast time domain sweep; IF, sweep, and video output ports AYX Not compatible with Options B7D, 304; occupies one expansion slot.
Includes capability of Option A4J
XX
Low emissions shielding 060 Not compatible with B7B X X
Preamplifi er built-in for enhanced sensitivity 1DS Operates to 3 GHz X X
100 Hz (30 Hz usable) frequency range extension UKB Requires Option 1DR X X
Digital demodulation hardware B7D/
B7E
Requires Option 1D5; not compatible with Option AYX;
occupies two expansion slots, must be ordered jointly
XX
APC 3.5 mm input connector BAB Available on the E4407B only X X
Bluetooth FSK demodulator 106 Requires Options B7D, 228; occupies one expansion slot X X
External mixing AYZ Available on E4407B only X X
EMI detectors quasi-peak and FM demodulation AYQ Occupies one expansion slot; requires Option 1DR X X
70 MHz IF out H70 Occupies one expansion slot X X X
Memory extension to 10 MB X B72 Included on all new instruments starting with SN US4144
or MY4144; required for fi rmware version A.08.00 or higher
XX
High stability frequency reference 1D5 E4401B X X X X
E4402B/04B/05B/07B (SN prefi x before 4421)
2
X
SN prefi xes US4421, MY4421, SG4421 or later
3
XX
IF sweep, video output ports A4J Not compatible with AYX; occupies one expansion slot X X
Applications and fi rmware
Noise fi gure measurement personality and hardware 219
1
See Option 219 Technical Overview for recommended options X X
Cable fault location measurement personality 225
1
Requires Option 1DN; recommended accessory
Option B7K; fi rmware available on Web, requires license key
X
Phase noise measurement personality 226
1
Firmware available on Web, requires license key X
Cable TV service and installation personality 227
1
Firmware available on Web, requires license key X
Bluetooth measurement personality 228
1
Requires Option 106, AYX requires Option 106 for full functionality X
Modulation analysis personality 229
1
Requires Options B7D/B7E, 1D5; includes capability of
Option 231; fi rmware available on Web, requires license key
X
ESA to 89601A vector signal analysis software link utility 231
1
Requires Options B7D/B7E, A4H,1D5;
Option 229 included capability of Option 231;
free download from Web; www.agilent.com/find/esa
X
EDGE upgrade on GSM 252
1
Requires Options BAH, B7D/B7E, A4H, 1D5;
requires Option 1DN for cable fault test
X
HP 8566/68 programming code compatibility 266
1
Free download from Web; www.agilent.com/find/esa X
8590 Series programming code compatibility 290
1
Free download from Web; www.agilent.com/find/esa X
GSM/GPRS measurement personality BAH
1
Requires Options 1D6
fi rmware available on Web, requires license key
X
cdmaOne measurement personality BAC
1
Firmware available on Web, requires license key
FM deviation personality enhancement J36
1
Requires Option BAA X
Customer upgradable Customer upgradable w/test Self-maintainers with Option 0BW & N7811A software
4
Return to service center Return to factory
1. If more than two or three measurement personalities are ordered, memory size limitations may limit the number that may be loaded into the ESA at any one time.
For detailed information about memory size limits, please see the Web site: http://sa.tm.agilent.com/ESA/memory/
2. For serial number prefixes less than US4421, MY4421, or SG4421, order E440xBK-1D5
3. For serial number prefixes US4421, MY4421, or SG4421 and later, order E440xBL-1D5
4. Self-maintainers are customers who service and calibrate their own instruments.
Information about the N7811A software can be found at: http://calsw.tm.agilent.com/
