ESA-E Communications Test Express Spectrum Analyzer (COM) – continued
Step 5. Choose measurement software
1
Description ESA-E spectrum analyzer EXA signal analyzer
Phase noise measurement Option 226 N9068A
Noise fi gure measurement Option 219
2
N9069A
GSM/GPRS measurement Option BAH
3,4
N9071A
EDGE upgrade to Option BAH Option 252
5
N9071A
Cable TV fi eld service and analog broadcast
measurement
Option 227 Not available
Modulation analysis measurement Option 229
6
89601X
89601A vector signal analysis (VSA) software 89601A – runs on external PC 89601A – runs internal to the instrument
8566/68 programming code compatibility Option 266
7
Not available
8590 Series programming code compatibility Option 290
7
Not available
cdmaOne measurement Option BAC
8
Not available
Future upgrades for the ESA-E standard express spectrum analyzer (STD/SG)
Available future expansion slots
E4402B – Three additional expansion slots
E4404/5/7B – Two additional expansion slots
1. If more than two or three ESA-E options are ordered, memory size may limit the number of options that can be loaded at any one time;
for detailed information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory
2. See ESA Noise Figure Measurement Personality Technical Overview, literature number 5989-0215EN, for recommended options
3. Requires Option B7D/B7E
4. Requires Options 1D5 and 1D6; includes capability of Option 225
5. Requires Option BAH
6. Requires Options B7D/B7E, A4H, and 1D5; includes capability of Option 231
7. Free download on the Web, no license required: http://www.agilent.com/find/esa
8. Requires Options B7D/B7E and 1D5
Express Analyzer and Bundle Equivalent Options
ESA-E express option or bundle ESA-E equivalent option(s) Additional information
STD- Standard analyzer AYX, BAA
STG- Standard analyzer with tracking generator AYX, BAA, 1DN
COM- Communication test analyzer B7D/B7E, 1D5, 1DR, BAA, 231
B75- Performance bundle 1DR, 1DS, 1D5 Only available with express analyzer STD or STG
304- Bluetooth
®
premium bundle 228,106, B7D/B7E, 1DS, 1D5 Options 106 and 228 are not available outside the
option bundle 304
The table below shows equivalent options in each bundle
offered for ESA-E spectrum analyzers.
