7
ESA-E Standard Express Spectrum Analyzer (STD/STG) – continued
Step 4. Add a preamplifier (preamplifiers are not standard)
Description ESA-E spectrum analyzer EXA signal analyzer
Preamplifier Option 1DS
1 MHz to 3 GHz
N9010A-P03
100 kHz to 3.6 GHz
Step 5. Add extra options
1
Description ESA-E spectrum analyzer EXA signal analyzer
Narrow resolution bandwidths
(recommended option)
Option 1DR Standard
Time-gated spectrum analysis Options 1D6 Standard
Performance bundle Option B75
2
For equivalency, order N9010A-PFR
Replace GPIB with serial port Option 1AX
3,4
Serial port unavailable; USB comes standard
50 Ω tracking generator Option 1DN, 9 kHz to 3 GHz Not available
Step 6. Choose measurement software
Description ESA-E spectrum analyzer EXA signal analyzer
Phase noise measurement Option 226
1
N9068A
Noise fi gure measurement Option 219
5,6
N9069A
Cable fault location measurement Option 225
7
Not available
Cable TV fi eld service and analog broadcast
measurement
Option 227 Not available
Benchlink Web remote software Option 230
8
Remote desktop come standard with the PC-based EXA
89601A vector signal analysis (VSA) software 89601A – runs on external PC 89601A – runs internal to the instrument
8566/68 programming code compatibility Option 266
9
Not available
8590 Series programming code compatibility Option 290
9
Not available
856xE/EC programming code compatibility Not available N9061A
Future upgrades for the ESA-E standard express spectrum analyzer (STD/SG)
Available future expansion slots
E4402B – Three additional expansion slots
E4404/5/7B – Two additional expansion slots
1. If more than two ESA-E options are ordered, memory size may limit the number of options that can be loaded at any one time; for detailed
information about memory size limitations, please see the Web site: http://sa.tm.agilent.com/ESA/memory
2. Includes Options 1D5, 1DR and 1DS
3. Requires one expansion slot
4. Not compatible with Option A4H
5. See ESA Noise Figure Measurement Personality Technical Overview, literature number 5989-0215EN, for recommended options
6. Requires one expansion slot
7. Requires Option 1DN; not compatible with Option BAH; recommended accessory Option B7K
8. Requires Option A4H
9. Free download on the Web, no license required: http://www.agilent.com/find/esa
