Agilent Technologies ESG Vector Signal Generator
E4423B, E4424B, E4425B, E4426B,
E4434B, E4435B, E4436B, and E4437B
Semi-Rigid Cable Replacement Kits
Kit Part Numbers: E4440-60750, E44000-60751, and E4400-60752
Introduction
This kit contains the parts and instructions to replace the semi-rigid cables on the E4438C Vector Signal Generator.
Installation includes the following steps:
1. Functionality Check.
2. Remove the outer and inner covers.
3. Remove daughterboard card cage boards.
4. Remove the old semi-rigid cables.
5. Install the new semi-rigid cables.
6. Replace daughterboard card cage boards.
7. Replace inner covers.
8. Verify the functionality of the signal generator.
9. Re-calibrate the signal generator.
10. Re-assemble the signal generator
11. Perform the functionality check of the signal generator.
Product Affected: . . . . . . . . . . . . . . . . . . . . . . . . . E4423B, E4424B, E4425B, E4426B,
E4434B, E4435B, E4436B, and E4437B
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . All
Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . All
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
( ) Personnel Qualified by Agilent Technologies
( ) Customer
Estimated Installation Time: . . . . . . . . . . . . . . . 1.0 hours
Estimated Verification Time: . . . . . . . . . . . . . . . 1.0 hours
