Installation Note E4440-90611 3
Wide Bandwidth Retrofit Kit
Wide Bandwidth Retrofit Kit
80 MHz Bandwidth Digitizer Retrofit Kit
40 MHz Bandwidth Digitizer Retrofit Kit
This retrofit kit provides all parts and instructions for installing Option 122, 80 MHz
Bandwidth Digitizer, or Option 140, 40 MHz Bandwidth Digitizer into your PSA Series
spectrum analyzer with the product number and serial number range listed above. The
kit installs an alternate 80 MHz or 40 MHz wide bandwidth IF path consisting of wide
band Analog IF and wide band Digital IF assemblies. Also, a wide bandwidth bandpass
filter and lowpass filter replaces the existing bandpass filter in the lowband (<3 GHz)
path.
NOTE 1. The installation of this kit requires that some performance testing be
performed in order to assure the new option is functioning properly.
This installation note includes a list of required performance tests.
Completing the list of required performance tests does not guarantee
the instrument meets all specifications.
NOTE 2. The instrument end user must determine whether they need a full
instrument calibration following the installation of the kit. If full
calibration is required, arrangements regarding the level of calibration
must be made between the end user and the calibration provider.
NOTE This option is licensed for one instrument model number/serial number
combination. The license key will only install on the designated
instrument.
Products Affected: PSA E4440A
PSA E4443A
PSA E4445A
Serial Numbers: US4611 /US99999999
MY4611 /MY99999999
SG4611 /SG99999999
To Be Performed By: (X) Agilent Service Center
( ) Personnel Qualified by Agilent
( ) Customer
Estimated Installation Time:
Estimated Adjustment and Verification Time:
Additional Recommended Task
3 Hours
3.5 Hours (see note 1)
Agilent recommends that a full calibration be
performed to verify instrument specifications
(see note 2)
