Agilent Technologies E4440A Installation Notes

4 Installation Note E4440-90611
Wide Bandwidth Retrofit Kit
Contents
Reference
Designator
Description Agilent Part
Number
A31 Wide Band Analog IF Assembly E4440-60215
A32 Wide Band Digital IF Assembly E4440-60262
FL2 Bandpass Filter, 3.900 GHz 0955-1391
FL3 Lowpass Filter, 4.4 GHz 0955-0519
W60 Cable, ribbon, A31 Wide Band Analog IF to
A32 Wide Band Digital IF
E4440-60341
W61 Cable (65), coax, 100 MHz Ref from A11 Reference Assy J2
to A31 Wide Band Analog IF P200
E4440-60344
W62 Cable (95), coax, 300 MHz Ref from A11 Reference Assy P4
to A31 Wide Band Analog IF P103
E4440-60346
W64 Cable (60), coax, Wide Band IF CAL from A31 Wide Band
Analog IF P101 to A10 3rd Converter J6
E4440-60345
W65 Cable (40), coax, 321.4 MHz IF from A10 3rd Converter J4
to A31 WB Analog IF P100
E4440-60385
W66 Cable (66), coax, 321.4 MHz from A31 WB Analog IF P104
to Rear Panel
E4440-60342
W78 Cable, semi-rigid, FL2 to FL3 E4446-20047
W79 Cable, Semi-rigid, FL3 to A20 Lowband J4 E4446-20048
Installation Note This note
Option Upgrade Entitlement Certificate ---
Cable tie .062D .09W
Basic Mode Guide
Specification Guide
