Agilent Technologies E4443A Service Guide

238 Chapter 10
Replaceable Parts Lists and Locations
Replaceable Parts
W22 Cable (70), coax, Ext
Ref In from rear panel to
A11 Reference Assy P1
8120-5053 X X X X X X
W23 Cable, coax, 28V to
rear panel from A13 Front
End Driver
8121-0958 X X X X X X
W24 Cable, semi-rigid, A21
SLODA to A12 Synthesizer
E4440-20082 X X X
W24 Cable, semi-rigid,
A21 FELOMA to
A12 Synthesizer
E4446-20036 X X X
W25 Cable, ribbon,
YTO Control
E4440-60069 X X X X X X
W26 Cable, ribbon,
RYTHM Control
E4440-60070 X X X X X X
W27 Cable, backlight
extension
(for serial prefix
US/MY/SG 4644 and above)
8121-1420 X X X X X X
W28 Wire harness, SLODA
control, from A13 Front End
Driver to A21 SLODA
E4440-60067 X X X
W29 Cable, ribbon,
A13 Front End Driver to
A14 Attenuator A
E4440-60071 X X X X X X
W30 Cable, ribbon,
A13 Front End Driver to
A15 Attenuator B
E4440-60071 X X X X X X
W31 Cable, ribbon,
A13 Front End Driver to
A20 Lowband Assy.
E4440-60072 X X X X X X
W32 not assigned
W33 Cable, semi-rigid, A15
Attenuator to W34
E4446-20022 X X X
W34 Cable, semi-rigid, W33
to A19 SBTX/RYTHM
E4446-20023 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
