Agilent Technologies E4443A Service Guide

Chapter 10 239
Replaceable Parts Lists and Locations
Replaceable Parts
W35 Cable, semi-rigid,
YTO Output A18 YTO to
A21 SLODA
E4440-20083 X X X
W35 Cable, semi-rigid,
YTO Output A18 YTO to
A21 FELOMA
E4446-20033 X X X
W36 Cable, semi-rigid,
A19 RYTHM to
FL1 Low Pass Filter
(except Option B7J)
E4440-20071 X X X
W36 Cable, semi-rigid,
A19 SBTX/RYTHM to
FL1 Low Pass Filter
(except Option B7J)
E4446-20031 X X X
W37 Cable, semi-rigid,
FL1 Low Pass Filter to
A20 Lowband Assy. J1
(except Option 1DS)
E4440-20074 X X X
E4446-20037 X X X
W38 Cable, semi-rigid,
LO signal A21 SLODA to
A19 RYTHM
E4440-20070 X X X
W38 Cable, semi-rigid,
LO signal A21 FELOMA to
A19 SBTX/RYTHM
E4446-20030 X X X
W39 Cable, semi-rigid,
Bandpass Filter Output, 3.9
MHz Bandpass Filter to
A20 Lowband J4
E4440-20081 X X X
E4446-20058 X X X
W40 Cable, semi-rigid,
Bandpass Filter Input,
A20 Lowband J3 to
FL2, 3.9 MHz Bandpass
E4440-20080 X X X
W41 Cable, semi-rigid,
A21 SLODA to
A20 Lowband Assy.
E4440-20076 X X X
W41 Cable, semi-rigid,
A21 FELOMA to
A20 Lowband Assy.
E4446-20034 X X X
W42 Cable, semi-rigid, A19
SBTX/RYTHM LO1 to AT1
E4446-20027 X X X
Table 10-3 Cables
a
Description Part
Number
E4440A E4443A E4445A E4446A E4447A E4448A
