308 Chapter 11
Assembly Replacement Procedures
Tools you will need
Tools you will need
Figure 11-1 TORX Tool
Adjustments after an instrument repair
Table 12-1 on page 412. If one or more instrument assemblies have
been repaired or replaced, perform the related adjustments and
performance verification tests.
Description Agilent Part Number
TORX Hand Driver - Size T10 8710-1623
TORX Hand Driver - Size T20 8710-1615
Pozidriv screwdriver - #1 8710-0899
flat blade screwdriver - 0.01 in. thick blade 8730-0008
9/16 inch nut driver 8720-0008
9/16 inch open-end wrench 8720-0010
5/16 inch open-end wrench
(for SMA cables)
8720-0015
1/4 inch open-end wrench
(for LO Out cable)
source locally
1/4 inch deep socket nut driver
(for SMA connector mounting)
source locally
cable puller 5021-6773
