Chapter 4
Front-Panel Key and SCPI Command Reference
Front-Panel Keys
152
Front-Panel Key and SCPI Command
Reference
4.2.8 Save/Load File Operations
4.2.8.1 Save
Saves the Power Sensor calibration factor information to a file. When access by front panel, the type of the file
should be set to Calibration first. And if necessary, the directory and the file name can also be set.
4.2.8.2 Load
Loads the Power Sensor calibration factor information from a file to the calibration factor editor. When access
by front panel, the type of the file should be set to Calibration first. And if necessary, the directory and the file
name can also be set.
NOTE Most of the SCPI command for the calibrate factors file operations is consistent with those in the
MMEMory subsystem, for example, Catalog, Delete, etc., except for Save and Load.
Mode: MRECEIVE
Key Path:
File, Save
Remote Command: :MMEMory:STORe:PSCFactor <‘file_name’>
Remote Command Notes: Global to the current mode.
Example: MMEMory:STORe:PSCF ‘C:\PSCF0001.XML
Mode: MRECEIVE
Key Path:
File, Load
Remote Command: :MMEMory:LOAD:PSCFactor <‘file_name’>
Remote Command Notes: Global to the current mode.
Example: MMEMory:LOAD:PSCF ‘C:\PSCF0001.XML
