5
Tools Required
• TORX T-10 driver
• TORX T-15 driver
• TORX T-20 driver
• 5/16” open-ended wrench
• Needle-nose pliers
•Scissors
Safety Considerations
WARNING Before you disassemble the instrument, turn the power switch off and
unplug the signal generator. Failure to unplug the signal generator can
result in personal injury.
CAUTION Electrostatic discharge (ESD) can damage or destroy electronic components. All
work on electronic assemblies should be performed at a static-safe workstation.
Table 3 E8251-60383, for Options 550 and 567
Item Quantity Description Part Number
1 1 Installation Note E8251-90302
2
1 Attenuator 90 dB E8251-60393
3 1 Semi-Rigid Cable (for Option 567) E8251-20319
4 1 Semi-Rigid Cable E8251-20320
5 1 Semi-Rigid Cable E8251-20322
6 1 Semi-Rigid Cable (for Option 567) E8251-20321
7 1 Semi-Rigid Cable (for Option 550) E8251-20025
8 1 Semi-Rigid Cable (for Option 550) E8251-20028
9 2 Mounting Screw 0515-1035
10 1 Entitlement Certificate n/a
