4 User’s Guide
E8362/3/4C Option H85
Specifications: Front Panel Jumpers and Test Ports
Specifications: Front Panel Jumpers and Test Ports
Specifications for Option H85 are the same as the standard E8362/3/4C PNA Series with
Option UNL. Specifications are available from the PNA Series Data Sheet at our web site:
http://www.agilent.com/find/pna
The high power, or large signal capability specifications for the Option H85 are not tested
at the factory, in the field or at service centers.
Table 1 Measurement Receiver Inputs
(RCVR A IN and RCVR B IN)
Description Typical (dBm)
Maximum Input Level
E8362CH85
45 MHz to 500 MHz –15
500 MHz to 2 GHz –11
2 GHz to 10 GHz −11
10 GHz to 20 GHz −11
E8363CH85
45 MHz to 500 MHz –14
500 MHz to 2 GHz –10
2 GHz to 10 GHz −10
10 GHz to 20 GHz −10
20 GHz to 30 GHz –14.5
30 GHz to 40 GHz –16.5
E8364CH85
45 MHz to 500 MHz –14
500 MHz to 2 GHz –10
2 GHz to 10 GHz −10
10 GHz to 20 GHz −10
20 GHz to 30 GHz –14.5
30 GHz to 40 GHz –16.5
40 GHz to 45 GHz −16
45 GHz to 50 GHz −15
Damage Level
E8362/3/4CH85 15 dBm
Maximum DC Level
E8362/3/4CH85 +15 V
