30 User’s Guide
E8362/3/4C Option H85
Service Information
Service Information
Servicing information can be found in the Agilent Technologies PNA Series Microwave
Network Analyzer E8362/3/4C Service Guide. Please visit our website at
http://www.agilent.com/find/pna.
Follow the Service Guide instructions for all repair, replacement procedures, tests and
adjustments.
Replaceable Parts
NOTE Special options are built to order, so long lead times may be encountered
when ordering replacement parts.
Reference
Designator
PNA Description
Agilent
Part Number
Add:
W63
1
1. W63 replaces W55, A38 and W83.
E8362C RF Cable: Port 1 CPLR THRU to A25 Test Port 1 Coupler E8362-20018
W63
1
E8363/4C RF Cable: Port 1 CPLR THRU to A25 Test Port 1 Coupler E8364-20073
W64
2
2. W64 replaces W56, A39 and W84.
E8362C RF Cable: Port 2 CPLR THRU to A26 Test Port 1 Coupler E8362-20019
W64
2
E8363/4C RF Cable: Port 2 CPLR THRU to A26 Test Port 1 Coupler E8364-20074
All
User’s Guide E8364-90040
All Overlay for Option H85 E8364-80013
Delete:
A38/A39 E8362C Bias-tee with cable 5086-7239
A38/A39 E8363/4C Bias-tee with cable 5086-7239
W55 All RF Cable: A38 bias tee to A25
Test Port 1 Coupler.
E8364-20167
W56 All RF Cable: A39 bias tee to A25
Test Port 1 Coupler.
E8364-20168
W83 E8363/4C RF Cable: Port 1 CPLR THRU to A38 Bias-Tee E8362-20012
W83
E8362C RF Cable: Port 1 CPLR THRU to A38 Bias-Tee E8364-20039
W84 E8363/4C RF Cable: Port 2 CPLR THRU to A39 Bias-Tee E8362-20013
W84 E8363/4C RF Cable: Port 2 CPLR THRU to A39 Bias-Tee E8364-20040
All Overlay for Options 815, 816 and 817 E8364-80024
