6 User’s Guide
E8362/3/4C Option H85
Specifications: Front Panel Jumpers and Test Ports
Table 3 Reference Outputs (Reference 1 SOURCE OUT
and Reference 2 SOURCE OUT)
Description Typical (dBm)
Maximum Output Level
E8362CH85
45 MHz to 500 MHz –24
500 MHz to 2 GHz –23
2 GHz to 10 GHz −23
10 GHz to 20 GHz −26
E8363CH85
45 MHz to 500 MHz –11.5
500 MHz to 2 GHz –10.5
2 GHz to 10 GHz −11
10 GHz to 20 GHz −11
20 GHz to 30 GHz –11
30 GHz to 40 GHz –11
E8364CH85
45 MHz to 500 MHz –11.5
500 MHz to 2 GHz –10.5
2 GHz to 10 GHz −11
10 GHz to 20 GHz −11
20 GHz to 30 GHz −11
30 GHz to 40 GHz −11
40 GHz to 45 GHz −11
45 GHz to 50 GHz −15
Damage Level
E8362/3/4CH85 20 dBm
Maximum DC Level
E8362/3/4CH85 ±15 V
