User’s Guide 9
E8362/3/4C Option H85
Specifications: Front Panel Jumpers and Test Ports
Table 6 Coupler Outputs (Port 1 CPLR ARM,
Port 2 CPLR ARM)
Description Typical
Damage Level
E8362/3/4CH85 30 dBm
Maximum DC Level
E8362/3/4CH85 7 V
Table 7 Test Port Input
Description Typical
Damage Level
E8362/3/4CH85 30 dBm
Maximum DC Level
E8362/3/4CH85 0 V
Table 8 Watts to dBm Conversion
Linear (Watts) Log (dBm)
0.001 0
0.01 10
0.100 20
130
233
436
10 40
20 43
40
46
50 47
100 50
200 53
