14 Chapter 1
Installation and Setup
Turning on the Analyzer for the First Time
Turning on the Analyzer for the First Time
o Plug in the power cord.
WARNING If this product is to be energized via an external auto transformer for voltage reduction,
make sure that its common terminal is connected to a neutral (earthed pole) of the power
supply.
CAUTION The analyzer is shipped with a a transportation disk inserted in the disk drive to prevent
damage to the disk drive during transportation. This transportation disk, or a blank floppy
disk, should be inserted in the disk drive whenever transporting the analyzer.
NOTE Do not connect anything else to the analyzer yet.
o Choose a power on preference using the switch on the rear panel (refer to Rear-Panel Features, on
page 32, item 14). The
PWR ALWAYS ON setting turns the analyzer on whenever external power is
applied. This mode is useful if an external power switch is used to control a rack of several
instruments. Nevertheless, if you set the analyzer to standby using the front panel
Standby key, and
the external power is removed and restored within 20 seconds, the analyzer will remain in standby.
The
PWR NORM setting assigns analyzer on/off control to the front-panel On and Standby keys (see
“Front-Panel Connectors and Keys” on page 24, item 23). If the analyzer is on and the external power
is removed and restored within 20 seconds, the analyzer will turn on. On the other hand, if the
external power is removed and restored after 20 seconds, the analyzer will remain in standby
regardless of the front-panel switch settings.
o Press the | (On) key to turn the analyzer on.
