Chapter 2 103
Front-Panel Key Reference
File
Setup Displays all setup (.SET) files you may
wish to copy. A Setup file is a complete
state of instrument parameters
including traces, states, limits and
corrections.
NOTE When using a personal computer to copy Setup files, ensure the
similarly named files with extensions like .s01, .so2, etc. are also copied.
These files are necessary to allow complete restoration of originally
saved Setup.
Key Access:
File, Copy, Type
State
Displays all state (.STA) files you may
wish to copy.
Key Access:
File, Copy, Type
Trace
Displays all trace (.TRC and .CSV) files
you may wish to copy.
Key Access:
File, Copy, Type
Limits
Displays all limit (.LIM) files you may
wish to rename.
Key Access:
File, Copy, Type
Screen
Displays all screen (.GIF and .WMF)
files you may wish to rename.
Key Access:
File, Copy, Type
Corrections Displays all corrections (.CBL, .ANT,
.OTH, .AMP) files you may wish to
rename.
Key Access:
File, Copy, Type, More
Signal List
Displays all signal list files you may
wish to copy and allows you to copy a
selected signal (.LST) list file. Signal
list files contains a list of signals which
include the frequency and measured
amplitudes for each signal.
Key Access:
File, Copy, Type, More
Report
Displays all report files you may wish
to copy and allows you to copy a
selected report (.HTM) file. Report files
can contain the screen in GIF format,
the signal list, and the analyzer setup.
The report files contain a hyperlink to
the GIF file of the analyzer screen. GIF
files can only be copied from a PC.
To Next Page
