Chapter 2 125
Front-Panel Key Reference
Meas Setup
4. Execute a SCPI remote commands that is the
equivalent to one of the items 1 through 3.
Key Access:
Meas Setup, 150 kHz - 30 MHz
30 - 300 MHz
Sets CISPR BAND C start frequency to 30 MHz and the stop to
300 MHz. The reference level is set to 80 dBuV in log scaling and the
units to dBuV. The resolution bandwidth is set to 120 kHz (Man
Couple), the marker is turned on as the active function, and the
following settings are set to Auto: video bandwidth, video bandwidth
ratio, sweep time, attenuation, and center frequency step size. Start
Frequency is made the frequency default.
This key sets the analyzer up for making CISPR BAND C
measurements. The analyzer settings for this setup are as follows:
Key Access:
Meas Setup
200 MHz - 1 GHz
Sets start frequency to 200 MHz and the stop to 1 GHz. The reference
level is set to 80 dBuV in log scaling and the units to dBuV. The
resolution bandwidth is set to 120 kHz, the marker is turned on as the
active function, and the following settings are set to Auto: video
bandwidth, video bandwidth ratio, sweep time, attenuation, and center
frequency step size. Start Frequency is made frequency default.
Description Setup
Start Frequency 30 MHz
Stop Frequency 300 MHz
Resolution Bandwidth 120 kHz
Video Bandwidth 300 kHz
Sweep Time Autocoupled
Reference Level 80 dBµV
Attenuation 5 dB
Detector Peak
Scale Type Log
Scale/Division 10 dB/Div
Marker 1 Normal, active
