150 Chapter 2
Front-Panel Key Reference
MEASURE
On Off This key is used to switch between signal list display
(split screen) and normal analyzer display. The upper
portion of the split screen is the active window with the
live trace. The lower portion of the screen displays the
signal list that contains the active (live) signal list item.
As the active signal list item is changed, the number
displayed in the menu key is updated to show the active
list item index. An annotation is maintained that shows
which item is current out of the total items (example: 1
of 8 or 44 of 200). A total of 2000 points can be added.
Key Access:
MEASURE, More, Signal List
Save/Load
Accesses menu keys that allow you to save analyzer
setups, states, traces, limits, corrections and screen
data to a floppy (A:) drive or internal flash (C:) drive.
NOTE Never remove the floppy disk during a save operation. To do so could
corrupt all data on the floppy disk.
Key Access:
MEASURE, More, Signal List
Load
Allows you to load a signal list file from
saved files of the graticule screen. Refer
to Load on page 98 for the available
menu options
Key Access:
MEASURE, More, Signal List,
Save/Load
Save Allows you to save a signal list file to a
floppy (A:) drive or internal flash (C:)
drive. Refer to
Save on page 94 for the
available menu options
Key Access:
MEASURE, More, Signal List,
Save/Load
List Edit
Accesses the submenu used to select which delta limit
parameters will appear in the signal list. It also enables
the selection of comments in the signal list.
Key Access:
MEASURE, More, Signal List
Signal List
On Off
Switches between signal list display
(split screen) and normal analyzer
display. The upper portion of the split
screen contains the live display. The
lower portion of the screen displays the
signal list. As the current signal list is
changed, the number displayed in the
menu key (list item index) is updated,
