Rear Panel Connections Getting Started
EPM-P Installation Guide 27
3. RJ11
4. Recorder output (two outputs are fitted to dual channel meters) and Trigger
Input and Output connections are made via BNC connectors.
Pin Connection
1 none
2 Ground
3 TTL Output 1
4 TTL Output 2
5 TTL Input 1
6 TTL Input 2
7 Ground
8 Ground
1 2 3 4 5 6 7 8
