Installation Note E4407-90041
3
Introduction
This procedure can be used to retrofit the APC 3.5 mm input connector (Option BAB) in E4407B, E4408B spectrum
analyzers, or E7405A EMC analyzers. One kit is provided for all model numbers.
To ensure that this newly installed option is functioning properly, the procedure that follows includes the requirement of
performing certain adjustments and performance verification tests. However, the completion of these tests does not guarantee
that the instrument meets all advertised specifications.
Software is required to perform the required adjustments, and can be used to automate the performance verification testing.
Information on how to obtain this software can be found at:
www.agilent.com/find/calibrationsoftware
While Agilent does recommend that a full calibration be performed after the installation of this upgrade, the end user must
ultimately determine whether they want this service or not. If a full calibration is required, arrangements regarding the level of
calibration must be made between the end user and the calibration provider.
Products Affected: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E4407B Spectrum Analyzer
E4408B Spectrum Analyzer
E7405A EMC Analyzer
Serial Numbers: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Any
Option: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BAB
To Be Performed By: . . . . . . . . . . . . . . . . . . . . . . . . . . . . (X) Agilent Technologies Service Center
(X) Personnel Qualified by Agilent
() Customer
Estimated Installation Time:. . . . . . . . . . . . . . . . . . . . . . . 2.0 Hours
Estimated Verification Time: . . . . . . . . . . . . . . . . . . . . . . 3.0 Hours
Additional Recommended Task: . . . . . . . . . . . . . . . Agilent recommends a full calibration be performed to verify
instrument specifications
