Agilent Technologies ESA-E Series Installation Note

Installation Note E4407-90041
4
Installation Kit Parts List
Tools Required
• T-10 TORX screwdriver
• T-15 TORX screwdriver
• Function generator
• Synthesized sweeper
• Digital voltmeter
• Power meter, dual channel
• RF Power sensor (2 required)
• Microwave power sensor
• 50 Ohm termination
• Power splitter
• 20 dB Attenuator (Option 1DS only)
• APC 3.5 (m) Cable
• APC 3.5 (m) to Type-N (m) Adapter
• APC 3.5 (m) to Type-N (f) Adapter
• BNC Tee (f,m,f)
• Dual banana to BNC (f) Adapter
Quantity Description Item Number
1 APC 3.5 connector assembly (A8J1) E4407-60002
1 Cable assembly, RF IN/ATTN (W6) E4404-20017
1 Adapter, APC 3.5 (f) to APC 3.5 (f) 5061-5311
1 Adapter, BNC (f) to SMA (m) 1250-1200
1 Option Upgrade Entitlement Certificate ---
1 APC 3.5 connector installation note E4407-90001
