110

8 Parts and Materials for Maintenance

Analytical-Head Assembly

Tabl e 21 Preparative-Head Assembly (900 µl) for G1329A only

Item Description Part Number

Analytical head assembly 900 µl

, includes items 1 – 6

This head is limited to 200 Bars

G1313-60007

1 Plunger assembly, 900 µl 5062-8587

2Screws 0515-0850

3 Adapter 01078-23202

4 Support seal assembly, 900 µl 5001-3764

5 Metering seal, 900 µl 0905-1294

6 Head body, 900 µl G1313-27700

7 Screw M5, 60 mm lg, for mounting of assembly (not shown

here)

0515-2118

Tabl e 22 Preparative-Head Assembly (900 µl) for G2260A

Item Description Part Number

Preparative head assembly 900 µl

, includes items 1 – 6

This head is limited to 400 Bars. It can only be assembled on a sampling unit with

the description “supports 900 µl at 400 Bar.

G2260-60007
