Agilent Technologies G7116A User Manual

Agilent InfinityLab LC Series Multicolumn Thermostats User Manual 68
3 Using the Module
Installing and Using Column ID Tags
5 Connect the flex cable to the column ID module.
a Open the locking mechanism of the connector by
lifting up the frame.
b Push in the cable with the contacts facing to the
rear.
c Close the locking mechanism.
d Verify that the cable is properly attached to the con-
nector without visible offset.
6 Attach the column ID module to the MCT cover.
1.
2.

Agilent Technologies G7116A Specifications

General

Brand	Agilent Technologies
Model	G7116A
Category	Laboratory Equipment
Language	English
