1260 Infinity II Binary LC System - Manual and Quick Guide 9
Introduction
1
System Components
Binary Pump G7112B
The Agilent 1260 Infinity II Binary Pump is suited for LC applications using
conventional or superficially porous particles columns, as well as STM column
technology. Gradient formation is based on a high-pressure mixing principle.
Standard or low delay volumes can be easily configured by the user. The
Agilent 1260 Infinity II Binary Pump offers reproducible gradients and
high-performance, providing high-throughput and fast separations. The pump
is suitable for routine applications, with UV or MS detection, where high speed
and resolution with uncompromised data quality are required.
Figure 1 Overview of the pump
Status indicator
Active seal wash
Purge valve
Degasser
Pump head A
Pump head B
Leak drain
Power switch
