Agilent Technologies HP 83712A Calibration Guide

-60
-80
t-4
5i -100
%
-120
-140
-160
IO
Ik
IOk 100k IM IOM
Offset (Hz)
Figure l-3.
Typical single-sideband phase noise at 1 GEL, 10 GFiz aud 20 GHz, 25’C, CW mode.
Oifsets less than 100 Hz require the high stability timebase, Option lE5.
Harmonics: c-50 dEk at output levels < + 6 dBm, 1 to 20 GHz
Figure l-4. Typical 2nd Harmonic Levels Measured at Output Power of + 6 dBm
Non-Harmonic Spurious (23 kHz): c-60 dEk (includes power supply and frequency synthesis
spurious).
Non-Harmonic Spurious (~3 hSk): < -50 dBc
Sub-Harmonfcs: None
HP 83711Ajl1BSpecifioations l-6
