Agilent Technologies HP 83712A Calibration Guide

Minimum Leveled Output Power (without Option 1El): -4 dBm
Minimum Leveled Output Power (with Option 1El): -90 dBm
Display Resolution: 0.01 dB
Accuracy: fl.O dB, 50 MHz to 20 GHz; f1.3 dB, 10 MHz to 50 MHz (-4 dBm to specified
maximum leveled output power).
Accuracy (over all spectied temperatures, frequencies and power levels)
10 MHz to 50 MHz: f2.3 dJ3
50 MHz to 20 GHz: f2.0 dB
The use of Type-N RF’ connectors above 18.0 GHz degrades specification typically by 0.2 dB.
10.5 -
h.o--5,~*rr.~lk.'L141+d
I?
$ 9.5
a -44.5
$4.0 m9waw---urrHb*
-85.5
0 4 a 12 16 20
CartWFrequency(GHz)
Figure 1-14. Typical Output Level Accuracy and Flatness at + 10 and -85 dBm
Flatness: f0.5 dB. The use of Type-N RF connectors above 18.0 GHz degrades specilkation
typically by 0.2 dB.
Level Switching lkne: Tgpicallg ~15 ms (without step attenuator range change
Attenuator range chunges occur at:
-SdBm,-14dBn,-24dBm,etc)
output SW& c2.0 : 1 nominal
