Minimum Leveled Output Power -4 dBm; -10 dBm linear AM (-110 dBm with
Option 1El)
Display Resolution: 0.01 dB
Accuracy: &l.O dB, 50 MHz to 20 GHz; f1.3 dB, 10 MHz to 50 MHz (-4 dBm to speci9ed
maximum leveled output power; with linear AM, -10 dBm to specified maximum leveled
output power)
Accuracy (over all power levels)
10 MHz to 50 MHz: f2.3 dB (power L-90 dBm)
50 MHz to 20 GHz: f2.0 dB (Power z-90 dBm);
10 MHz to 20 GHz f2.5 dB (power c-90 dBm)
The use of Type-N RF’ connectors above 18.0 GHz degrades specification typically by 0.2 dB.
Figure l-23. Typical Output Level Accuracy and Flatuess at + 10 and -85 dBm
Flatness: f0.5 dE3 (Power 1 -90 dBm); f0.7 dES (Power < -90 mm). The use of Type-N RF’
connectors above 18.0 GHz degrades specification typically by 0.2 dB.
Level Switching Tinze: Tgpicallg cl7 ms (without step attenuator range change).
Attenuator range changes occur at:
-10 dBm, -20 dBm, -30 d&n, etc (Linear AiIQ
-4 d&t, -14 d&n, -24 dBm, etc(aU other modes)
chL@ut swR.- c2.0 : 1 !wminul
